Larry Witmer has made a true gem accessible to WitmerLab readers… Ghetie’s Atlas of Avian Anatomy. I’m too busy right now to do more than browse through it but be assured: it’s 285 pages of lavishly illustrated guts and bones of domestic birds.
preface, overview of the domestic birds (rooster / chickens, ducks, guinea-fowl, pigeon), osteology (skeletals), circulatory, digestive, respiratory, urogenital, nervous & gland systems.
Go get it!
Some of you may have noticed that I’ve been absent lately. Indeed, I’ve been … gone.
Well, more than gone. Whisked away by the first tornado spout I’ve ever seen in Germany. It was an awkward mini-storm, hardly deserving the name. And certainly of only distant relation to the beast that had me cowering in a storm cellar in Minnesota for two hours. We drove right past this one, fascinated because there was no storm front, no cloud base to speak of. Yet there it was.
It did manage to whisk me and Tatjana off to a strange, docile land where steak-sized meals pave the forests, begging to be honored with digestion. Just as we’d first arrived, we saw that we’d decapitated this fellow. We’ve been trying to make amends. He tasted fantastic.
Since then we’ve been having some remarkable encounters with the local fauna, one of wish I’m particularly eager to share with you … Read more »
As an insect molts… just moved to a new host. Perhaps I’ll shake off some parasitic bots and Russian babes sites that have been sending the most traffic this way. Doubt it, but anyway…
Time to jellify my innards and prepare for some metamorphosis.
I contacted Mark Witton, author of Pterosaurs, which I’ve been reading with some artist-centric questions about his book. Mark’s been great in answering, but I think we’re both a bit too busy at the moment, so this is much more a dialog than an interview. My intention was to take advantage of Mark’s artistic abilities to ask questions visually… feel free to add questions or comments.
How should your skeletals be interpreted? is there any fore-shortening or are they – as I suspect – constructed on flat plans? There are a few places where this makes for potentially large differences of interpretation… as in the hand digits, the humerus and the femur.
Mark Witton: The diagrams are on 2D planes. I think the takeoff pose used in them reduced most aspects of foreshortening, as the arm, for instance, is extended to the point where all the limb bones are more-or-less operating in the same plane. This, of course, wouldn’t be the case if the limbs were folded up tightly, because pterosaur limbs – the forelimbs in particular – don’t work entirely uniaxially.
Your book gives a thorough idea of what parts of the pterosaur anatomy are open to interpretation… except the uropatagium. You draw it unattached to the tail on page 52 (left). I’m biased: it looks like a baggy squirrel suit for RedBull stunt divers. The tail-attached version feels like a real animal design. You point to papers talking about the toe and thigh attachment but not – despite ALL THAT SPACE on page 55 – anything about the tail. What’s the hard knowledge on this? a) Are there biases in the evolution (ie. probability of a membrane forming between along tail edge vs between tail and ass)? b) Are there aerodynamic considerations… wouldn’t the attached version allow for more finely-tuned flight control? The unattached version would require leg movements to alter the uropatagium’s position, but the legs are also defining the main wing surface.
Mark Witton: I guess I did forget to mention the relationship of the tail to the uropatagium. This is probably because – despite what you see in many reconstructions – there is no evidence that the tail is incorporated into the uropatagium in any pterosaur fossil. The only good uropatagium we have preserved in an early pterosaur (actually, perhaps in any pterosaur) belongs to the holotype of Sordes, in which the tail is markedly deflected laterally without any affect on the symmetry of the membrane. This is presumably because the tail was not attached to the membrane at all (this is reflected in the illustration of wing membrane distribution in chapter 5 of my book, showing a long tailed pterosaur with the tail skewed to the left). Indirect evidence for a lack of tail incorporation in early pterosaurs stems from anuronathids. These taxa have long fifth toes, which are almost certainly reflecting a broad uropatagium, but many anurognathids have very dumpy tails which cannot, for obvious reasons, be operating the posterior membrane. So yes, there may be good mechanical reasons to think the membrane was attached to the tail, but there’s no fossil evidence for it. Unwin and Bakhurina’s (1994) work on Sordes uropatagium remains the seminal work on this issue.
I tried to model the uropatagium in a rough 3D sketch. I modeled a body and tail form from your skeletals, then tried three different uropatagium variations: attached, free and a partial attachment somewhere along the base of the tail. Posed as in your skeletal, there’s not much chance of getting the free version to work out (middle above). It would have to move way down to the dorsal surface, which would kill any aerodynamic function. I had to bend his tail up just make it look half-way functional. At the very least, the tail would be pressed against this u. surface much of the time. The other two versions seem more plausible imo. Sound right?
Mark Witton: I think the reason you were having trouble fitting the tail over the top of the uropatagium is that the tail base is far too thick. Check out the caudal myology reconstructions of Rhamphorhynchus by Scott Persons: http://pterosaur-net.blogspot.co.uk/2013/01/guest-post-dragon-tails-what-pterosaurs.html
There’s virtually no muscle on them whatsoever, even at the base. The characteristically big caudofemoralis of most archosaurs is all but gone. The tail is essentially a bony rod with a slither of soft-tissue around it, and would probably easily extend above the uropatagium without impacting on it. I also note that the membrane in your diagrams is does not connect along the midline of the leg, but is dorsally deflected. I don’t think any fossils show us exactly where the membrane attached with respect to the midline of the leg (some experts in animal flight may have some ideas, though), but this may also be influencing the intrusion of the tail into the uropatagium.
More soon! (‘soon’ paleontologically speaking)
As the German-language Spiegel reports, visitors to a Chinese zoo were tipped off to a zoological sham when a lion (clearly indicated as such via signage) barked rather than roared. Certainly, wily innovators at the Discover Channel are watching the case closely… there’s potential here for dinosaur safaris (ostrich suits) and even a megalodon tank (Whale shark with dentures?). Apparently, the key lies in making sure everything roars.
